Adobe User Group Tour
As you probably know, we launched the first public betas for Flash Builder 4, Flash Catalyst, and Flex SDK 4 in June 2009. And we had about 100 events across the world, events that were driven by the communities (Adobe User Groups). I had the pleasure to present at four events: Amsterdam, Netherlands; Bucharest, Romania; Zagreb, Croatia; and Pavia, Italy.
I think all the events went great, and personally I had great fun doing the presentations and talking with the people afterwards. But, from my point of view the Adobe User Group from Netherlands deserves a special mention. Somehow the Netherlands, of all the events I’ve attended so far, has something special that is hard to find in other places. And I am not talking only about the Adobe User Groups events, I found that this is true also for events organized by the PHP community for example.
The location was extraordinary, the audience was big (more than 200 people) and very eager to ask questions, and there was good food and cold beverages, including after hours beer. I can’t stop thinking how it would be to have a MAX event in Amsterdam
The organizers taped the event. So, in case there wasn’t a Tour event near you, you can see here the presentations Christoph Rooms and I gave on Flash Catalyst, Flex SDK 4, and Flash Builder 4.
Data Paging with Flex and PHP in Flash Builder
Flash Builder 4 can really speed up the development of data-driven applications. There are new wizards that can help you create the data service and the data model on the client side, and map client side operations to server side operations (CRUD applications). This post is an introduction to the new Data/Services view from Flash Builder 4 (I am using a PHP server and a PHP class).
In this article I will focus on how to use the available wizards to do data paging. While this new feature can handle ColdFusion, Java, REST style services, and SOAP services, in this post I will use PHP. Data paging is very useful when you have large sets of data. Basically, using this feature, you can bind a data grid to a server operation that manages a large table, and only 20 records will be sent to the client at one time. As you scroll through the data grid and reach areas where you don’t have data yet, a new request is made for that region and another page of records is brought into the client.
PHP code
On the server side I have two classes. One is the data model for my data, VOEmployee:
1: <?php
2: class VOEmployee {
3:
4: public $emp_no;
5: public $birth_date;
6: public $first_name;
7: public $last_name;
8: public $gender;
9: public $hire_date;
10: public $phone_no;
11: public $email_address;
12: public $job_title;
13: }
14: ?>
This class wraps a record from the MySQL table. The second class is the PHP service itself, Employees.php.
1: <?php
2: require_once 'VOEmployee.php';
3:
4: //conection info
5: define("DATABASE_SERVER", "localhost");
6: define("DATABASE_USERNAME", "mihai");
7: define("DATABASE_PASSWORD", "mihai");
8: define("DATABASE_NAME", "employees");
9:
10: /**
11: $o = new Employees();
12: $o->count();
13: */
14:
15: class Employees {
16:
17: private $_con;
18:
19: public function Employees() {
20: $this->_con = mysql_connect(DATABASE_SERVER, DATABASE_USERNAME, DATABASE_PASSWORD);
21: if (!$this->_con)
22: $this->throwError();
23: mysql_select_db(DATABASE_NAME);
24: }
25:
26: public function getAllItems($lastName) {
27: if ($lastName==NULL) {
28: $sql = 'SELECT * FROM employees';
29: } else {
30: $sql = 'SELECT * FROM employees WHERE last_name LIKE \'%'.mysql_escape_string($lastName).'%\'';
31: }
32: $result = mysql_query($sql, $this->_con);
33: if (!$result)
34: $this->throwError();
35: $ret = array();
36: while ($row = mysql_fetch_object($result, "VOEmployee")) {
37: $ret[] = $row;
38: }
39: mysql_free_result($result);
40: return $ret;
41: }
42:
43: public function getItem($itemID) {
44: $sql = 'SELECT * FROM employees WHERE emp_no = '.mysql_escape_string($itemID);
45: $result = mysql_query($sql, $this->_con);
46: if (!$result)
47: $this->throwError();
48: $ret = mysql_fetch_object($result, "VOEmployee");
49: mysql_free_result($result);
50:
51: return $ret;
52: }
53:
54: public function createItem($item) {
55: $sql = 'INSERT INTO employees (first_name, last_name, gender, email_address, hire_date, birth_date, job_title) VALUES (';
56: $sql .= '\'' . mysql_escape_string($item->first_name) . '\', ';
57: $sql .= '\'' . mysql_escape_string($item->last_name) . '\', ';
58: $sql .= '\'' . mysql_escape_string($item->gender) . '\', ';
59: $sql .= '\'' . mysql_escape_string($item->email_address) . '\', ';
60: $sql .= '\'' . mysql_escape_string($item->hire_date) . '\', ';
61: $sql .= '\'' . mysql_escape_string($item->birth_date) . '\'';
62: $sql .= ')';
63: $result = mysql_query($sql, $this->_con);
64: if (!$result)
65: $this->throwError();
66: return NULL;
67: }
68:
69: public function updateItem($item) {
70: $sql = 'UPDATE employees SET ';
71: $sql .= 'first_name = \'' . mysql_escape_string($item->first_name) . '\', ';
72: $sql .= 'last_name = \'' . mysql_escape_string($item->last_name) . '\', ';
73: $sql .= 'gender = \'' . mysql_escape_string($item->gender) . '\', ';
74: $sql .= 'email_address = \'' . mysql_escape_string($item->email_address) . '\', ';
75: $sql .= 'hire_date = \'' . mysql_escape_string($item->hire_date) . '\', ';
76: $sql .= 'birth_date = \'' . mysql_escape_string($item->birth_date) . '\', ';
77: $sql .= 'job_title = \'' . mysql_escape_string($item->job_title) . '\'';
78: $sql .= ' WHERE emp_no = ' . mysql_escape_string($item->emp_no);
79:
80: $result = mysql_query($sql, $this->_con);
81: if (!$result) {
82: $this->throwError();
83: }
84: return NULL;
85: }
86:
87: public function deleteItem($itemID) {
88: $sql = 'DELETE FROM employees WHERE emp_no = ' . mysql_escape_string($itemID);
89: $result = mysql_query($sql, $this->_con);
90: if (!$result)
91: $this->throwError();
92: return NULL;
93: }
94:
95: public function count() {
96: $sql = 'SELECT COUNT(emp_no) AS empCount FROM employees';
97: $result = mysql_query($sql, $this->_con);
98: if (!$result)
99: $this->throwError();
100: $row = mysql_fetch_object($result);
101: $ret = $row->empCount + 0;
102: mysql_free_result($result);
103: return $ret;
104: }
105:
106: public function getItems_paged($startIndex, $numItems) {
107: $sql = 'SELECT * FROM employees LIMIT ' . mysql_escape_string($startIndex) . ', ' . mysql_escape_string($numItems);
108: $result = mysql_query($sql, $this->_con);
109: if (!$result)
110: $this->throwError();
111:
112: $ret = array();
113: while ($row = mysql_fetch_object($result, "VOEmployee")) {
114: $ret[] = $row;
115: }
116: mysql_free_result($result);
117: return $ret;
118: }
119:
120: private function throwError($message="") {
121: if ($this->_con)
122: $message .= 'Error no: ' . mysql_errno($this->_con) . '. Message: ' . mysql_error($this->_con);
123: throw new Exception($message, 1);
124: }
125: }
126:
127:
128: ?>
While this service implements all the CRUD operations, actually I’ll use only two methods for my example: getItems_paged() and count().
Flex code
On the client, I created a Flex project that uses PHP as the server side technology, and then I added a data grid.
1: <?xml version="1.0" encoding="utf-8"?>
2: <s:Application xmlns:fx="http://ns.adobe.com/mxml/2009" xmlns:s="library://ns.adobe.com/flex/spark" xmlns:mx="library://ns.adobe.com/flex/halo" minWidth="1024" minHeight="768">
3: <mx:DataGrid x="42" y="40">
4: <mx:columns>
5: <mx:DataGridColumn headerText="Column 1" dataField="col1"/>
6: <mx:DataGridColumn headerText="Column 2" dataField="col2"/>
7: <mx:DataGridColumn headerText="Column 3" dataField="col3"/>
8: </mx:columns>
9: </mx:DataGrid>
10: <s:layout>
11: <s:BasicLayout/>
12: </s:layout>
13: </s:Application>
Next, using the Data/Services panel you can add a new data service (choose PHP from the wizard’s first page), and point the wizard to the PHP class Employees.php. After completing this step, you need to define the Return Type for the getItems_paged() method. Right-click on the method and choose Return type. Next add a name (Employee) and make sure you select the int type for the two arguments. Finally set some values for these two arguments 1 and 20, for example.
All these steps I’ve already explained in detail in my previous post. Now let’s add the paging capabilities. Right-click on the getItems_paged() method from the Data/Services view, and choose from the menu Enable Paging…. In the first page of the wizard select the primary key property of the Employee data model:
And, in the second page select the count method from the dropdown (this step is optional; if you don’t specify a count() method, then when the data grid is rendered the height of the scrollbar’s thumb is not correlated with the number of the records. Usually the more data you have, the thinner the thumb will be):
Click Finish, and then bind the getItems_paged() operation to the data grid (Go to Design mode, select the operation from the Data/Services view and drag-and-drop over the data grid). And actually this is all you have to do. This is how the Employees data services looks:
When you run the application, it should look like this:
Changing the Page size
You’ve probably noticed that the wizard doesn’t provide any means to control the size of the page. And if you take a look at the Network Monitor and you inspect the result, you’ll see that the page size is set to 20 records.
If you want to change the size, you can do it programmatically using the property pageSize of the DataManager class (you can see the doc for this class here). And you can obtain the DataManager instance for your service using the getDataManager() method on the service. The code looks like this:
1: var d:DataManager = employees.getDataManager(employees.DATA_MANAGER_EMPLOYEE);
2: d.pageSize = 10;
3:
4: [...]
5:
6: <employees:Employees id="employees" destination="Employees"
7: endpoint="http://localhost/dataPaging-debug/gateway.php"
8: fault="Alert.show(event.fault.faultString)"
9: showBusyCursor="true" source="Employees"/>
What could go wrong
If you are not able to add data paging to your data service, the PHP method probably doesn’t have the correct number of arguments or the arguments don’t have the expected names (please don’t ask me why it has to be this way). Here is the error message:
Secondly, when you run your application you could see this error:
Most likely, this error is due to the wrong type of the value returned by the PHP count() method. You’ll get this error if you write your code like this:
1: $sql = 'SELECT COUNT(emp_no) AS empCount FROM employees';
2: $result = mysql_query($sql, $this->_con);
3: $row = mysql_fetch_object($result);
4: $ret = $row->empCount;
5: mysql_free_result($result);
6: return $ret;
In this case $ret variable will be a string, and when the values is received by the Flex code it is a int or number, and thus the error. So, just make sure you cast the $ret variable to int. You can do something like this:
1: $ret = $row->empCount + 0;
Conclusion
You can download the project from here (in the project you’ll find in the project a folder called services; copy the two PHP files to your webserver, and use the db.sql to create the table; next make sure you set the correct credentials for database access in the Employees.php file). Finally, you might want to generate again the whole data service, in order to have the gateway.php file generated (this file is created in the Flex output folder of the project, and this folder doesn’t get exported so you won’t find it in my project).
I’m a big fan of IDE features that can save you from tedious tasks or eliminate repetitive tasks. And this feature I think saves you time. You can check for more articles on Adobe Developer Connection, or even better, download Flash Builder 4 and play with it. Be sure to let me know what you think.
MAX LA 2009
MAX 2009 is coming fast. Cornel and I will do a lab on LiveCycle Data Services and BlazeDS, so for us, the work has already started. But being a speaker, means you don’t have to pay for your ticket
Which brings me to this: on June 16th we launched the MAX session catalog and scheduler, and if you don’t have a ticket you should check this page (you can find all the choices you have for buying a ticket).
Here are some choices you might be interested in:
- Full conference pass bought until August 31st $1,295
- Group discount price pass (three or more attendees from the same company) $1,095
- Full conference pass for government, education, and nonprofit $995
- $400 off on the regular price $1,495 if you purchase select products between July 13th – October 2nd (more here)
See you there!
First Android phone with Flash Support: HTC Hero
Today, we announced with our OSP partners HTC that for the first time Adobe Flash Player will be available on an Android phone, HTC Hero. You can find out more about what this means for users and developers on Mark Doherty’s blog, Ryan Stewart’s blog, Adobe Developer Connection (Adrian Ludwig gives a video introduction on the device), and the press release.
You can see below a snapshot from Adrian’s movie, in which he uses HTC Hero to visit Yahoo! Movies, a site that uses a lot Flash content.
I want one of these right now
Round-trip Flash Catalyst and Flash Builder 4?
One question I heard a lot in the last weeks was about the round-trip between Flash Catalyst and Flash Builder 4. Out of the box, there is no round-trip between these two products. We do, however, support round trip between Flash Catalyst and Illustrator/Photoshop, and between Flash Builder 4 and Flash Professional CS 4.
Let’s take this workflow:
- The designer creates the user interface in Illustrator
- Using Flash Catalyst he transforms the static design into a functional design
- He hands the FXP project created by the Flash Catalyst tool to the developer
- The developer imports the FXP project into Flash Builder 4 and starts to add client logic and data services
- The designer has to change something, and wants to work directly on the developer’s project.
This is the message you get when you try step 5:
What are the challenges for a round-trip between Fc and Fb?
Why does this limitation exist in the first place? Before answering this question, let me tell you that we definitely want to have a round-trip between these two products, and we might have it in the future (keep in mind that Flash Catalyst is a version 1 product). Now, if you have a look at how a developer can work in Flash Builder 4 you can see two main approaches: Design view, or Code view. Sometimes you create custom components, and you do a lot of tricks and magic in order to create the desired application, and when you switch to Design view, nothing appears on the screen. This is really no big deal, because you can continue work in Code view, and press the Run button to check the application.
However, if you are the designer, and you work in Flash Catalyst, then all you have is the design view. If the design view can not render the application user interface and interactions on the stage, then the designer can’t work at all. Imagine trying to work on an Illustrator file without being able to visualize the document. It is really the same situation.
The solution
After giving this matter some thought, I think there is some kind of a round-trip that can be employed between these two products.
There are couple of things you need to do in order to succeed:
- The designer always keeps an instance of the FXP project that will not be touched by the developer. For example when he gives the FXP to the developer, he makes sure that he also keeps a copy of that file.
- The developer does his magic on the file received from the designer.
Now, suppose the designer has to modify the UI of the application to accommodate client’s wishes. He opens his FXP project, and makes all the changes. When he finishes, he gives a copy of the project to the developer. It doesn’t matter what kind of changes the designer made; if you look at the project you might find: new files, files deleted, existing files changed.
Which means that the easiest way to merge the designer changes into the developer project is by using a Merge tool or File/Folder Comparison tool such as Araxis. And just to illustrate my point, I added a new button in Flash Catalyst, then I saved the project. After this I unzipped the new project in a folder called v2 and the first version (or the developer’s project) in a folder called v1. Then, using Araxis I compare the two folders:
I can see very quickly if there are new files (like Button4.mxml), or if there are changes in the existing files (like Main.mxml). In the next image you can see the differences highlighted for Main.mxml.
Finally, there is a way to see the generated code in Flash Catalyst it self, and even to change it. Flash Catalyst offers a Code view (on the top-right corner you can choose between Code and Design view):
If you go in Code view, actually you can see the project as it will appear in Flash Builder when imported. While being in Code view, if you open an MXML file, you can see the code, but you cannot change it. And this is perfect, because, as I said, this is a designer tool and designers usually don’t work with code, but with tools. If you really want to play with the code inside of Flash Catalyst (maybe you are a designer/developer), you right-click on a file and choose to open it with Text Editor, then you can actually change it inside of the tool. But keep in mind, you might ruin the Design view by doing this.
Conclusion
I am not saying this is easy to do. But I really think it can speed up the integration of the designer changes into the developer project. And because we are still working on version one of the Flash Catalyst, we are still thinking and figuring out things.
Please, let me know what your opinion is on this matter.
RTMP specification is out
We announced earlier this year that we’d open up the specifications for Real-Time Messaging Protocol (RTMP is the protocol used by Flash Media Server and LiveCycle Data Services). We did it today, and you can read the details here.
Basically you can download the specifications and start implementing your own servers that make use of this highly efficient protocol for sending data between Adobe Flash Player or Adobe AIR apps and various servers.
It is worth noting that we didn’t open up anything related to RTMPe – Adobe’s implementation to secure the content. While you as a developer don’t have access to our implementation, you are free to implement your own secure implementation on top of RTMP.
User Group Tour Zagreb :: Flex + Flash…
This Thursday, June 18th, I have the pleasure of presenting sessions on Flash Catalyst, Flash Builder, and Flex Framework 4 in Zagreb, Croatia. You can find details on the event here. If you live nearby, come and let’s have a great day. See you!
Acrobat.com: new tools available
If you haven’t logged into your Acrobat.com account lately, you might be surprised because we’ve added two new tools: Tables (a spreadsheet tool) and Presentations (a presentation tool).
All the nice features you have in Buzzword (real time collaboration, sharing, versioning) are available for these two products as well. Bellow you can see screenshots with the products (if you want to play with them, just go to https://labs1.acrobat.com).
